reanimate

Reanimate is a reactive framework for creating non-interactive animations from SVG images. This package consists of a set of arrow combinators, a renderer (using ffmpeg), and a Gtk-based previewer. Inline latex code is supported when 'latex' and 'dvisvgm' are installed.

Nothing about the API is stable at this point.

The example gifs are displayed at 25 fps.

TODO

• bounding boxes
• alignment and positioning combinators
• automatic code reloading in the Gtk viewer
• website for live coding

Examples

Drawing latex equations

latex_draw :: Ani ()
latex_draw = pauseAtEnd 1 $ defineAnimation $ proc () -> do
  emit -< rect_ [width_ "100%", height_ "100%", fill_ "black"]
  drawText msg `andThen` fillText msg -< ()
  where
    msg = "\\sum_{k=1}^\\infty {1 \\over k^2} = {\\pi^2 \\over 6}"
    placement = g_ [transform_ $ translate 20 15 <> " " <> scale 5 5]
    fillText txt = defineAnimation $ proc () -> do
      duration 1 -< ()
      s <- signal 0 1 -< ()
      emit -< placement $
          g_ [fill_ "white", num_ fill_opacity_ s] $
            toHtml $ latexAlign txt
    drawText txt = defineAnimation $ proc () -> do
      duration 2 -< ()
      s <- signal 0 1 -< ()
      emit -< placement $
          g_ [stroke_ "white", fill_opacity_ "0", stroke_width_ "0.1"] $
            toHtml $ partialSvg s $ latexAlign txt

Bounding boxes

bbox :: Ani ()
bbox = proc () -> do
  emit -< rect_ [width_ "100%", height_ "100%", fill_ "black"]
  annotate' bbox1 -< g_ [transform_ $ Lucid.translate (320/2-50) (180/2)]
  annotate' bbox2 -< g_ [transform_ $ Lucid.translate (320/2+50) (180/2)]

bbox1 :: Ani ()
bbox1 = defineAnimation $ proc () -> do
  duration 5 -< ()
  s <- signal 0 1 -< ()
  let rotated = rotate (360*s) svg
      (x, y, w, h) = boundingBox rotated
  emit -< do
    g_ [transform_ $ Lucid.translate x y] $
      rect_ [num_ width_ w, num_ height_ h, stroke_ "red", fill_opacity_ "0"]
    g_ [fill_ "white"] $ toHtml rotated
  where
    msg = "\\sum_{k=1}^\\infty"
    svg = scale 3 $ center $ latexAlign msg

bbox2 :: Ani ()
bbox2 = defineAnimation $ proc () -> do
  duration 5 -< ()
  s <- signalOscillate 0 1 -< ()
  let rotated = partialSvg s heartShape
      (x, y, w, h) = boundingBox rotated
  emit -< do
    g_ [transform_ $ Lucid.translate x y] $
      rect_ [num_ width_ w, num_ height_ h, stroke_ "red", fill_opacity_ "0"]
    g_ [fill_ "white", fill_opacity_ "0", stroke_width_ "4", stroke_ "white"] $
      toHtml rotated

Bezier curves

Sine wave

sinewave :: Ani ()
sinewave = proc () -> do
    duration 10 -< ()
    emit -< rect_ [width_ "100%", height_ "100%", fill_ "black"]

    idx <- signalOscillate 0 1 -< ()
    emit -< do
      defs_ $ clipPath_ [id_ "clip"] $
        rect_ [x_ "0", num_ y_ (-height), num_ width_ (idx * width), height_ "100%"]
      g_ [transform_ $ translate margin height, clip_path_ "url(#clip)"] $
        renderPath $ approxFnData 1000 wave
      line_ [ num_ x1_ margin, num_ x2_ margin, y1_ "10", y2_ "170"
            , stroke_ "white"]
      line_ [num_ x1_ margin, num_ x2_ (margin+width), num_ y1_ height, num_ y2_ height
            , stroke_ "white"]

    let (circX, circY) = wave idx
    emit -< g_ [transform_ $ translate margin height] $
      circle_ [num_ cx_ circX, num_ cy_ circY, r_ "3", fill_ "red"]
  where
    freq = 3; margin = 30; width = 260; height = 90
    wave idx = (idx*width, sin (idx*pi*2*freq) * 50)

Morphing wave

morph_wave :: Ani ()
morph_wave = proc () -> do
    duration 5 -< ()
    emit -< rect_ [width_ "100%", height_ "100%", fill_ "black"]

    morph <- signalOscillate 0 1 -< ()
    emit -< do
      g_ [transform_ $ translate 30 50] $ renderPath wave1
      g_ [transform_ $ translate 30 130] $ renderPath wave2
      g_ [transform_ $ translate 30 90] $ renderPath $ morphPath wave1 wave2 morph
      line_ [x1_ "30", x2_ "30", y1_ "10", y2_ "170", stroke_ "white"]
      line_ [x1_ "30", x2_ "290", y1_ "90", y2_ "90", stroke_ "white"]
  where
    freq = 3; width = 260
    wave1 = approxFnData 1000 $ \idx -> (idx*width, sin (idx*pi*2*freq) * 20)
    wave2 = approxFnData 1000 $ \idx -> (idx*width, sin (idx*pi*2*(freq*3)) * 20)

Morph wave to circle

morph_wave_circle :: Ani ()
morph_wave_circle = proc t -> do
  duration 5 -< ()
  emit -< rect_ [width_ "100%", height_ "100%", fill_ "black"]

  idx <- signalOscillate 0 1 -< ()
  emit -< do
    g_ [transform_ $ translate 30 90] $
      renderPath $ morphPath circle wave1 idx
    line_ [x1_ "30", x2_ "30", y1_ "10", y2_ "170", stroke_ "white"]
    line_ [x1_ "30", x2_ "290", y1_ "90", y2_ "90", stroke_ "white"]
  where
    freq = 5; width = 260; radius = 50
    wave1 = approxFnData 1000 $ \idx -> (idx*width, sin (idx*pi*2*freq) * 20)
    circle = approxFnData 1000 $ \idx ->
      (cos (idx*pi*2+pi/2)*radius + width/2, sin (idx*pi*2+pi/2)*radius)

Speed modification

progressMeters :: Ani ()
progressMeters = proc () -> do
  emit -< rect_ [width_ "100%", height_ "100%", fill_ "black"]
  annotate' (adjustSpeed 1.0 progressMeter) -< g_ [transform_ $ translate 40 20]
  annotate' (adjustSpeed 2.0 progressMeter) -< g_ [transform_ $ translate 140 20]
  annotate' (adjustSpeed 0.5 progressMeter) -< g_ [transform_ $ translate 240 20]

  emit -< do
    text_ [x_ "55", y_ "150", font_size_ "20"
          , text_anchor_ "middle"
          , fill_ "white"] "1x"
    text_ [x_ "155", y_ "150", font_size_ "20"
          , text_anchor_ "middle"
          , fill_ "white"] "2x"
    text_ [x_ "255", y_ "150", font_size_ "20"
          , text_anchor_ "middle"
          , fill_ "white"] "0.5x"

Highlights

Clipping

clip_rect :: Ani ()
clip_rect = proc () -> do
  emit -< rect_ [width_ "100%", height_ "100%", fill_ "black"]
  follow
    [ proc () -> do
      sim [ paintStatic prev | prev <- [max 0 (n-4) .. n-1] ] -< ()
      sim [ runAni "black" i | i <- [n-4], i>=0 ] -< ()
      runAni "white" n -< ()
    | n <- [0..15]
    ] -< ()
  where
    paintStatic nth = proc () ->
      annotate' (obj "white" (20+nth*10) (20+nth*10))
        -< g_ [transform_ $ translate 160 90]
    runAni color nth = defineAnimation $ proc () ->
      annotate' (circle_clip (obj color (20+nth*10) (20+nth*10)))
        -< g_ [transform_ $ translate 160 90]
    obj c width height = proc () -> do
      duration 1 -< ()
      emit -< rect_ [ num_ width_ width, num_ height_ height
            , num_ x_ (-width/2), num_ y_ (-height/2)
            , stroke_ c, fill_opacity_ "0", stroke_width_ "2" ]

scaling

Animations can be reused, scaled and stretched in time. This example reuse four different animations of different lengths, scales their runtime so they're all in sync, and increases the playback speed.

scaling :: Ani ()
scaling = adjustSpeed 2 $ syncAll
  [ defineAnimation $ proc () ->
    annotate' animation -< g_ [transform_ $ translate x y <> " " <> scale 0.5 0.5]
  | x <- [0,160]
  , y <- [0,90]
  | animation <- [sinewave, morph_wave, highlight, progressMeters]]

Valentine's Day

Basic LaTeX

latex_basic :: Ani ()
latex_basic = proc () -> do
  duration 2 -< ()
  s <- signalOscillate 0 1 -< ()
  emit -< rect_ [width_ "100%", height_ "100%", fill_ "black"]
  emit -<
    g_ [transform_ $ translate 20 15 <> " " <> scale 4 4] $ do
      g_ [stroke_ "white", fill_opacity_ "0", stroke_width_ "0.1"] text
      g_ [fill_ "white", num_ fill_opacity_ s]                     text
  where
    text = latex "\\sum_{k=1}^\\infty {1 \\over k^2} = {\\pi^2 \\over 6}"
